JIKONG BMS Product Update: V23.5 & V22 Series Bring Pre-charge Protection, Dual RS485, and Direct Parallel Connection

JIKONG BMS Product Update: V23.5 & V22 Series Bring Pre-charge Protection, Dual RS485, and Direct Parallel Connection

JKVOLT announces a comprehensive firmware and hardware upgrade across its popular BMS product lines. The latest V23.5 and V22 versions introduce significant improvements in safety, communication, and installation compatibility, with mass production scheduled from September through October 2026.

This update covers 10 key BMS models across the BD Series, PB Series, and B1A/B2A Series, all available now or entering production at jkvolt.com.

What's New in the V23.5 & V22 Upgrades?

The latest generation delivers three major improvements across most models:

  • Pre-charge Function – Limits inrush current when connecting to inverters or loads, preventing capacitor surges and protecting both the BMS and connected equipment.

  • Enhanced Short Circuit Protection – Faster response times and more sensitive detection to safeguard battery cells under fault conditions.

  • Dual RS485 Support – The "-R" function now supports 2 channels of RS485 interface, covering 24V and 12V energy storage applications.

Selected models also gain direct parallel connection for LiFePO4 batteries (parallel control interface removed), smaller physical dimensions, and new ABS plastic shells with higher insulation withstand voltage.

Model-by-Model Breakdown

JK-BD6A24S-4PD — V23.5

Pre-charge function and more sensitive short circuit protection added. Dimensions and mounting holes unchanged — a drop-in upgrade for existing installations. Mass production: late September.

JK-BD4A24S-4P — V23.5

Added pre-charge function, more sensitive short circuit protection, ACC removed, smaller size, and mounting holes changed. Over 4,000 units currently in stock. Mass production: late September.

JK-BD6A24S-8PD — V23.2

Pre-charge and enhanced short circuit protection. Dimensions and mounting holes unchanged. Already in mass production.

JK-BD6A24S-15PD — V23.5

After V20.3 (2x M6) and V23.3 (1x M8, discontinued), the V23.5 returns to 2x M6 terminals, adds pre-charge, and reduces size. V20.3 and V23.3 are discontinued. V23.5 mass production: August 20 batch.

JK-BD6A24S-6P — V23.5

Shares the 24S-4P V23.5 circuit board. Adds pre-charge and enhanced short circuit protection. Smaller size affects installation. Mass production: late September.

PB1A16S-10/15/20P — V24.1

Appearance change only (top cover bent design). Does not affect usage or assembly. 20P model mass production: late September; other models pending.

JK-B1A8S-10P — V22.0

Smaller size, mounting holes changed. Dual RS485 supports 24V/12V energy storage. Direct parallel connection for LiFePO4 (parallel control interface canceled). Specific variants (10PH, 10PR, 10PCR, 10PS, 10PHS) begin with the 8.20 batch. Mass production: October.

JK-B1A8S-20P — V22.2

Smaller size, mounting holes changed. Dual RS485 and direct parallel connection. Limited stock of previous version available now. Mass production: October.

JK-B2A8S-30P — V22.0

Smaller size, mounting holes changed. Dual RS485 and direct parallel connection. Mass production: October.

JK-B2A24S — V22.3

Smaller size, mounting holes changed. New ABS plastic shell for higher insulation withstand voltage. ⚠️ Critical power supply adjustment: The power supply cable can ONLY be connected to battery cells — DO NOT connect to the power module. Mass production: October.

Frequently Asked Questions (FAQ)

Q: What is the pre-charge function and why does it matter?
A: The pre-charge function limits the inrush current when connecting the BMS to an inverter or capacitive load, preventing the BMS from triggering short-circuit protection during startup. This is essential for smooth, reliable system operation.

Q: Can I use my old mounting bracket with the new V23.5/V22 models?
A: It depends on the model. JK-BD6A24S-4PD and JK-BD6A24S-8PD have unchanged mounting holes. JK-BD4A24S-4P, JK-BD6A24S-6P, and all V22 models have smaller dimensions and changed mounting holes, requiring a new installation plan.

Q: What does the dual RS485 update mean for my 24V/12V system?
A: The -R function now supports 2 channels of RS485 interface, enabling seamless communication in 24V and 12V energy storage applications.

Q: Can I connect LiFePO4 batteries directly in parallel now?
A: Yes. The parallel control interface has been canceled on the V22.0/V22.2 models, allowing LiFePO4 batteries to be directly connected in parallel.

Q: What is the most important wiring change for JK-B2A24S V22.3?
A: The power supply cable must only be connected to the battery cells. Do not connect it to the power module. This is a critical safety and operational change.

Availability & Where to Buy

All upgraded models are available at jkvolt.com. Browse the full JIKONG BMS collection with the latest V23.5 and V22 firmware and hardware revisions.

  • In Stock Now: JK-BD6A24S-8PD (V23.2), JK-BD4A24S-4P (V23.5, 4,000+ units), JK-B1A8S-20P (limited V22.2 stock)

  • Late September Mass Production: JK-BD6A24S-4PD, JK-BD4A24S-4P, JK-BD6A24S-6P, PB1A16S-20P

  • October Mass Production: JK-B1A8S-10P, JK-B1A8S-20P, JK-B2A8S-30P, JK-B2A24S

Upgrade your battery management system with the latest JIKONG technology. Shop Now at jkvolt.com →
